Battle Born Power Station 3000

Description

The Battle Born Power Station 3000 is an industrial-grade portable energy system built for demanding off-grid use, mobile work, and reliable backup power.

With 3,000W of continuous pure sine wave output and 2.5kWh of LiFePO4 energy storage, it delivers clean, quiet power for tools, appliances, and sensitive electronics without the noise or fumes of a traditional generator.

Designed for harsh environments, it features integrated heating, weather-sealed construction, and flexible charging from solar, vehicle, or grid power. Built for durability and assembled in North America, it is a strong fit for job sites, field operations, and serious portable power needs.

Best For:

• Mobile jobsites and field operations
• Off-grid work and remote deployments
• Emergency backup power
• Service vehicles and industrial use
• Portable power for tools, appliances, and electronics

Features

• Smart Battery Monitoring
  Built-in Bluetooth and Dragonfly IntelLigence® technology provide real-time visibility into battery performance and system health.
• Wireless System Communication
  Supports wireless mesh connectivity for integration with compatible smart power systems.
• Integrated Heating Technology
  Internal heating system warms battery cells in cold conditions to allow safe charging at low temperatures.
• Cold-Weather Charging Capability
  Maintains usability in environments where standard lithium batteries cannot charge effectively.
• High-Capacity GC3 Form Factor
  Delivers 270Ah of lithium power in a space-efficient footprint for demanding installations.
• True Deep Cycle LiFePO4 Performance
  Provides 100% usable capacity with stable lithium chemistry for reliable, long-term energy delivery.
• Integrated Battery Management System (BMS)
  Protects against voltage, temperature, and short circuit conditions for safe operation.
• Expandable System Design
  Supports series up to 48V and parallel configurations for scalable battery systems.
• Long Cycle Life
  Designed for 3,000–5,000 cycles for extended service life.
• Flexible Installation
  Can be mounted in multiple orientations for easier integration into custom battery compartments.

Specifications

Official Specification Sheet (PDF)

Warranty
30 Month Warranty

Battery Type
LiFePO4 (Lithium Iron Phosphate)

Energy Storage
2.5kWh

Power Output
3,000W continuous

Surge Power
4,500W (500ms), 6,000W (10ms)

Sine Wave Output
Pure sine wave

Cycle Life
3,500+ cycles

AC Output
120V AC

Frequency
60Hz

Solar Input Power
1,600W

Solar Input Voltage Range
30–80V DC

Max Solar Amperage
40A

Alternator Input
30A

Grid Charging Power
1,200W

Bypass Power
1,200W

12V DC Accessory Output
12V regulated DC output up to 160W

Auto Generator Start
Supports generators with two-wire auto-start; starts at approximately 15% battery and stops at approximately 85%

Output Efficiency
>90%

Operating Temperature
-22°F to 122°F (-30°C to 50°C)

Storage Temperature
-22°F to 122°F (-30°C to 50°C)

Recharge Time
Grid: 2.5 hours
Solar: 2 hours with maximum solar power

Idle Power Consumption
40W

Humidity Range
5%–95%

Vibration Resistance
IEC 60068-2-64

Shock Resistance
IEC 60068-2-31

Dimensions
23.8" L × 15.5" W × 13.2" H

Weight
75.6 lbs (34.3 kg)

Certifications
CE, UL9540A, UL1642, ESA SPE-1000, UL1741

Safety Protections
Solar reverse polarity protection, overload protection, short circuit protection, surge protection, and over-temperature shut-off

Origin
Assembled in North America

Power Station 3000 vs Power Station Pro 5000

Which One Should You Choose?

• Power Station 3000 – Ideal for portable power, RV use, and everyday backup needs where mobility and simplicity matter.
• Power Station Pro 5000 – Built for high-demand applications, extended runtime, and powering larger tools or equipment in off-grid environments.
• If portability and lighter weight matter, the 3000 is the better fit.
• If you need maximum power and longer runtime, the Pro 5000 is the better choice.

What's Included

• Battle Born Power Station 3000
• Alternator/Solar connecting adapter
